C-600P CHEM-FEED DIAPHRAGM PUMP

Max Feed: 16.2 GPH (61.3 LPH)
Max Pressure: 125 PSI (8.6 bar)
Categories: , , Tag:

Description

  • Economical and versatile.
  • All ball bearing, permanently lubricated gear motor for smooth, quiet, powerful operation.
  • Turndown Ratio is 27:1
  • Stroke adjustment from 4-100% permits accurate small injections at a high rate per minute.
  • Double-ball inlet and outlet cartridge type check valves
  • Diaphragm material = PTFE

CONSTRUCTION

enclosure:

  • Durable metal epoxy coated construction

Wetted Parts:

  • PTFE coated EP diaphragm
  • Double-ball inlet and outlet cartridge type ceramic check valves.
  • Chemical resistant PVDF pump head, valve body and fittings, ceramic balls, FKM static seals and TFE/P ball seat orings. No metal springs are used.

MOTOR

  • All ball bearing, permanently lubricated gear motor for smooth, quiet, powerful operation.

SHIPPING ACCESSORIES

  • Includes 3/8” OD suction and discharge tubing, Injection fitting with spring-loaded check valve and all mounting
  • PVDF suction (foot) valve with FKM and TFE/P o-rings, ceramic check ball and removable polypropylene filter screen.

Additional information

Max. working pressure:

125 psig (8.6 bar)
Max. fluid temperature:

130° F (54° C)
Max. ambient temperature:

14 to 110° F/ -10 to 46° C
Maximum viscosity:

1,000 Centipoise
Maximum suction lift:

10 ft. Water, 0 psig
Output Adjustment Range:

4 – 100% stroke length
Duty cycle:

Continuous
Enclosure:

NEMA type 1 (IP20)
Operating Voltage:

115VAC/60Hz, 1ph (.74 Amp Maximum)
230VAC/60Hz, 1ph (0.36 Amp Maximum)
220VAC/50Hz, 1ph (.31 Amp Maximum)
24VAC/60Hz, 1ph (3.40 Amp Maximum)
12VDC (3.00 Amp Maximum)
24VDC (1.50 Amp Maximum)
Power Connection:

Junction box for field wiring
Approx. Shipping Weight:

8 lb. (3.6 Kg)
